Description
Style BX
Durlon® Style BX gaskets have a pitch diameter slightly larger than the groove pitch diameter. This allows for initial contact to be made on the outside of the ring, pre-loading the gasket which creates a pressure energized seal. This style of RTJ features a pressure passage to enable trapped pressure to balance itself in the joint and can only be used with API BX flanges.
Additional information
| Gasket Material | 316SS, L.C.S. |
|---|---|
| BX Gasket Name | BX-150, BX-151, BX-152, BX-153, BX-154, BX-155, BX-156, BX-157, BX-158, BX-159, BX-160, BX-169 |
