170CA-4-2
Parker’s Compress-Align fittings require no flaring, soldering or other preparation of tubing. The captive sleeve is always oriented for correct installation, visible for inspection before and after installation.
Orientation: ELBOW
End 1 Type: FNPT
End 1 Size: 1/4
End 2 Type: TUBE
End 2 Size: 1/8
Description
| Shape: | Elbow 90° |
| Configuration: | Tube to Female Pipe |
| Connection 2 Type: | Female Pipe |
| Minimum Operating Temperature: | -65 °F, -54 °C |
| Maximum Operating Temperature: | 250 °F, 121 °C |
| Maximum Operating Pressure: | 2800 psi, 193 bar |
| Tube Material: | Copper, Aluminum, TFE, FEA, PFA, Thermoplastic |
| Materials of Construction: | Brass (Nut), Brass (Sleeve) |
| For Fluid Type: | Water, Air, Inert Gases, Non-combustible Gases |
| Connection Type: | NPTF |
| Application: | Compressors, Machine Tools, Dispensing, Pumps, Purification |
| Connection 1 Tube Outside Diameter: | 1/4″ (O.D.) |
| Connection 1 Type: | Compression |
| Body Material: | Brass, Forged |
| Connection 2 Thread Size: | 1/8″ |
