B17
Orientation: STRAIGHT
End 1 Type: FNPT
End 1 Size: 1/2
End 2 Size: 1/2
Description
| Body Size (inch): | 1/2 |
| Connection Thread Size (inch): | 1/2 – 14 |
| Maximum Operating Pressure: | 300 psi |
| Media: | Low pressure fluids and compressed air, Low pressure fluids and compressed air |
| Coupling Half: | Coupler |
| Specifications Met: | Tru-Flate design, Connects with A-A-59439 (MIL-C-4109F, ISO 6150-B |
| Minimum Operating Temperature: | -40 °F |
| Sleeve Type: | Manual |
| Maximum Operating Temperature: | 250 °F |
| Lock Type: | Locking balls |
| Valve Type: | Tubular |
| Plating Type: | na |
| Body Material: | Brass |
| Seal Material: | Nitrile |
| Application: | Air |
| Connection Hose I.D. (inch): | na |
| Thread Style: | Female |
| Connection Type: | NPTF |
